Policetech Telecamera Bullet 6Mp IPC-B8339TC-A-IL
POLICEtech IPC-B8339TC-A-IL IP VIDEO SURVEILLANCE CAMERA
6Mp (3200 × 1800) - 20fps / Lens 110° / Min. Illumination: 0.007 LUX / IR LED range up to 30m / Power Consumption max. 4W / Human detection
Acquista in totale sicurezza
Spedizione in 24h
Consegna express disponibile
Restituzioni entro 14 giorni
Continuando a navigare su questo sito web, accetti il nostro utilizzo dei cookie e dei tuoi dati personali secondo il GDPR dell'UE.
Vedi Dettagli
Nostra Privacy Policy
Our Privacy Policy explains our principles when it comes to the collection, processing, and storage of your information. This policy specifically explains how we employ cookies, as well as the options you have to control them.
-
1 Cosa sono i cookies?
Cookies are small pieces of data, stored in text files that are stored on your computer or other device when websites are loaded in a browser. They are widely used to "remember" you and your preferences, either for a single visit or for multiple repeat visits
-
2 Come usiamo i cookies
Utilizziamo i cookie per diversi scopi. Alcuni cookie sono necessari per motivi tecnici; alcuni consentono un'esperienza personalizzata sia per i visitatori che per gli utenti registrati; e alcuni consentono la visualizzazione di pubblicità da reti di terze parti selezionate.
-
3 Cookie di controllo
I visitatori potrebbero voler limitare l'uso dei cookie o impedirne completamente l'impostazione. Se disabiliti i cookie, tieni presente che alcune delle funzionalità del nostro servizio potrebbero non funzionare correttamente
-
4 Informazioni che collezioniamo
Raccogliamo informazioni su di te solo se abbiamo un motivo per farlo, ad esempio per fornire i nostri servizi, per comunicare con te o per migliorare i nostri servizi.
We are committed to maintaining the trust and confidence of our website visitors. We do not collect, sell, rent or trade email lists or any data with other companies and businesses. Have a look at our Privacy Policy page to read detail information on when and why we collect your personal information, how we use it, the limited conditions under which we may disclose it to others and how we keep it secure.
We may change Cookies and Privacy policy from time to time. This policy is effective from 24th May 2018.
IPC-B8339TC-A-IL
Camera
Image Sensor: 1/2.7" CMOS
Max. Resolution: 3840 (H) × 2160 (V)
ROM: 128 MB
RAM: 256 MB
Scanning System: Progressive
Electronic Shutter Speed: Auto/Manual, 1/3 s–1/100,000 s
Minimum Illumination:
0.008 lux @ F1.6 (Color, 30 IRE)
0.0008 lux @ F1.6 (B/W, 30 IRE)
0 lux (Illuminator on)
S/N Ratio: > 56 dB
Illumination Distance: Up to 30 m (IR and warm light)
Illuminator On/Off Control: Auto / Manual
Illuminator Number: 1 (Multi-core IR + warm light)
Angle Adjustment:
Pan: 0°–360°
Tilt: 0°–90°
Rotation: 0°–360°
Lens
Lens Type: Fixed-focal
Lens Mount: M12
Focal Length: 2.8 mm
Max. Aperture: F1.6
Field of View (2.8 mm):
Horizontal: 110°
Vertical: 58°
Diagonal: 132°
Iris Control: Fixed
Close Focus Distance: 1.5 m
DORI Distance
Detect: 84.8 m
Observe: 33.9 m
Recognize: 17.0 m
Identify: 8.5 m
DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining how clearly a person or object can be distinguished. Values listed are not for intelligent function detection. Refer to the installation manual or project design tool for intelligent detection ranges.
Intelligence
Human Detection: Supports classification and accurate detection of humans
Smart Search: Works with Smart NVR for refined intelligent search, event extraction, and merging to event videos
Video
Compression: H.265, H.264, H.264H, H.264B, MJPEG (sub-stream only)
Smart Codec: Smart H.265+, Smart H.264+
Frame Rate:
Main stream: 3840 × 2160 @ 1–20 fps / 2688 × 1520 @ 1–25/30 fps
Sub stream: 704 × 576 @ 1–25 fps / 704 × 480 @ 1–30 fps
Maximum frame rates are per stream; actual rates depend on total encoding capacity.
Streams: Dual-stream
Resolutions Supported:
8M (3840 × 2160), 6M, 5M, 4M, 3M, 1080p, 1.3M, 720p, D1, VGA, CIF
Bit Rate Control: CBR / VBR
Bit Rate Range:
H.264: 32 kbps–8192 kbps
H.265: 12 kbps–8192 kbps
Day/Night Mode: Auto (ICR) / Color / B/W
BLC / HLC / WDR: Supported (DWDR)
White Balance: Auto, Natural, Street Lamp, Outdoor, Manual, Regional Custom
Gain Control: Auto / Manual
Noise Reduction: 3D NR
Motion Detection: On/Off (4 areas)
Region of Interest (RoI): 4 areas
Smart Illumination: Supported
Image Rotation: 0° / 90° / 180° / 270° (90°/270° supported up to 2688 × 1520 resolution)
Mirror: Supported
Privacy Masking: Up to 4 areas
Audio
Built-in Microphone: Yes
Audio Compression: G.711a, G.711Mu, PCM, G.726
Alarm
Events:
Network disconnection
IP conflict
Illegal access
Motion detection
Video tampering
Audio detection
SMD (human)
Security exception
Network
Port: RJ-45 (10/100 Base-T)
SDK / API: Supported
Protocols:
IPv4, IPv6, HTTP, TCP, UDP, ARP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, DHCP, DNS, DDNS, NTP, Multicast, ICMP, IGMP, P2P
Interoperability: ONVIF (Profile S & T), CGI
Users: 6 users, total bandwidth 48 Mbps
Storage: FTP
Browser Support: IE, Chrome, Firefox
Management Software: Smart PSS Lite, DSS, DMSS, DoLynk Care
Mobile Clients: iOS, Android
Cybersecurity:
Video/configuration encryption
Digest authentication
WSSE, Account lockout, Security logs
X.509 certificate support
HTTPS
Trusted boot, execution, and upgrade
Certification
CE-LVD: EN62368-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
Power
Supply: 12 VDC / PoE (802.3af)
Consumption:
Basic: 2.5 W (12 VDC), 3.5 W (PoE)
Max: 4.5 W (12 VDC), 5.8 W (PoE) (with H.265, intelligence, DWDR, and max illumination)
Environment
Operating Temp: –40 °C to +60 °C
Humidity: ≤95% RH, non-condensing
Storage Temp: –40 °C to +60 °C
Storage Humidity: ≤95% RH, non-condensing
Protection: IP67
Structure
Material: Metal
Dimensions: 173.3 mm × 70.0 mm × 70.0 mm
Net Weight: 0.46 kg
Gross Weight: 0.57 kg
IPC-B8339TC-A-IL
Scheda tecnica
- Case
- Bullet
- Risoluzione
- 6MP
- Tipologia
- Telecamera per videosorveglianza
- Batteria inclusa
- No/Non necessaria
POLICEtech IPC-B8339TC-A-IL IP VIDEO SURVEILLANCE CAMERA
6Mp (3200 × 1800) - 20fps / Lens 110° / Min. Illumination: 0.007 LUX / IR LED range up to 30m / Power Consumption max. 4W / Human detection
